产品选择器
43 个了局
Loading
|
Part No
|
Status
|
Function
|
Supply Voltage (V)Min
|
Supply Voltage (V)Max
|
Output Current (A)Max
|
Ron (mΩ) HSFET
|
Ron (mΩ) LSFET
|
Reference Voltage (V)
|
Quiescent Current (μA)
|
Switching Frequency (MHz)
|
Note
|
Temperature Operating Range(°C)
|
Package
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MP | BUCK | 2.5 | 6 | 1 | 200 | 150 | 0.6 | 25 | 1.5 | SS/Comp./Current Mode | -40 to +85 | SOT235 | |
| MP | BUCK | 2.5 | 6 | 1 | 200 | 150 | 0.6 | - | 1.5 | SS/Comp./Current Mode/FCCM | -40 to +85 | SOT235 | |
| MP | BUCK | 2.5 | 6 | 1 | 200 | 150 | 0.6 | 25 | 1.5 | SS/Comp./Current Mode | -40 to +85 | SOT563 | |
| MP | BUCK | 2.5 | 6 | 1.2 | 200 | 150 | 0.6 | 25 | 1.5 | SS/Comp./Current Mode | -40 to +85 | SOT235 | |
| MP | BUCK | 2.5 | 6 | 1.2 | 200 | 150 | 0.6 | - | 1.5 | SS/Comp./Current Mode/FCCM | -40 to +85 | SOT235 | |
| MP | BUCK | 2.7 | 5.75 | 2 | 65 | 60 | 0.6 | 35 | 1.5 | SS/Comp./Current Mode | -40 to +85 | SOT235 | |
| MP | BUCK | 2.7 | 5.75 | 2 | 65 | 60 | 0.6 | - | 1.5 | SS/Comp./Current Mode/FCCM | -40 to +85 | SOT235 | |
| NRFND | BUCK | 4.5 | 18 | 2 | 110 | 60 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT563 | |
| NRFND | BUCK | 4.5 | 18 | 2 | 110 | 60 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT236 | |
| NRFND | BUCK | 4.5 | 18 | 2 | 110 | 60 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT563 | |
| NRFND | BUCK | 4.5 | 18 | 2 | 110 | 60 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.2 | 18 | 2 | 113 | 80 | 0.6 | 250 | 0.6 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.2 | 18 | 2 | 113 | 80 | 0.6 | 250 | 1.2 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.5 | 18 | 3 | 80 | 45 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT563 | |
| MP | BUCK | 4.5 | 18 | 3 | 80 | 45 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.5 | 18 | 3 | 80 | 45 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT563 | |
| MP | BUCK | 4.5 | 18 | 3 | 80 | 45 | 0.8 | 250 | 0.8 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.5 | 18 | 6 | 21 | 16 | 0.6 | 750 | 0.2-1.6 | SS/Comp./Current Mode/FCCM | -40 to +150 | QFN14 | |
| NRFND | BUCK | 4.5 | 25 | 3 | 50 | 40 | 0.6 | 175 | 0.5 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.5 | 36 | 2 | 150 | 78 | 0.6 | 300 | 0.5 | Current Mode | -40 to +125 | SOT236 | |
| MP | BUCK | 4.5 | 36 | 3 | 120 | 80 | 0.8 | 150 | 0.52 | ACOT | -40 to +125 | ESOP8 | |
| MP | BOOST | 2.5 | 18 | - | - | 150 | 0.6 | 110 | 1 | Current Mode | -20 to +85 | SOT236 | |
| MP | BOOST | 2.5 | 18 | - | - | 150 | 0.2 | 110 | 1 | Current Mode | -20 to +85 | SOT236 | |
| MP | BOOST | 0.9 | 5.5 | - | 600 | 300 | 0.5 | 1 | 1 | Current Mode | -40 to +125 | SOT236 | |
| MP | BOOST | 0.9 | 5.5 | - | 600 | 300 | 0.5 | 1 | 1 | Current Mode | -40 to +125 | SOT236 | |
| MP | BUCK | 4.2 | 18 | 2 | 95 | 70 | 0.6 | 260 | 0.8 | ACOT | -40 to +85 | SOT563 | |
| MP | BUCK | 4.2 | 18 | 2 | 113 | 80 | 0.8 | 250 | 0.6 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.2 | 18 | 2 | 95 | 70 | 0.8 | 260 | 0.8 | ACOT | -40 to +85 | SOT563 | |
| MP | BUCK | 4.2 | 18 | 2 | 113 | 80 | 0.765 | 250 | 0.6 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.5 | 18 | 3 | 95 | 60 | 0.6 | 250 | 0.6 | ACOT | -40 to +85 | SOT236 | |
| MP | BUCK | 4.5 | 36 | 2 | 150 | 78 | 0.6 | 300 | 0.5 | Current Mode | -40 to +125 | SOT236 | |
| MP | BUCK | 4.2 | 28 | 3 | 90 | 40 | 0.6 | 130 | 0.6 | ACOT | -40 to +125 | SOT236 | |
| MP | BUCK | 4.5 | 70 | 3 | 180 | N/A | 0.8 | 150 | 0.25-1.2 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 70 | 3 | 180 | N/A | 0.8 | 150 | 0.25-1.2 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 65 | 5 | 80 | N/A | 0.803 | 130 | 0.2-1.2 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 100 | 2 | 600 | N/A | 0.78 | 190 | 0.15/0.24/0.42 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 100 | 3.8 | 500 | N/A | 0.78 | 190 | 0.15/0.24/0.42 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 100 | 1 | 500 | 200 | 0.78 | 220 | 0.3-0.8 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 100 | 2 | 400 | 120 | 0.78 | 240 | 0.3-0.8 | ACOT | -40 to +125 | ESOP8 | |
| MP | BUCK | 4.5 | 100 | 1 | 900 | N/A | 0.78 | 180 | 0.46 | ACOT | -40 to +125 | SOT236 | |
| MP | BUCK | 4.5 | 100 | 3 | 100 | N/A | 0.78 | 70 | 0.45 | ACOT/Low side MOS gate driver | -40 to +125 | ESOP8 | |
| MP | BUCK MODULE | 2.5 | 6 | 3 | N/A | N/A | 0.6 | 20 | 2.4 | COT | -40 to +125 | EMLGA10-2X2.5X1.25 | |
| MP | BUCK MODULE | 2.9 | 7 | 6 | N/A | N/A | 0.6 | 20 | 1.2 | COT | -40 to +125 | EMLGA19-3X3X1.55 |
