产品选择器
16 个了局
Loading
|
Part No
|
Supply Voltage Range Vs (V)
|
Channel
|
Common Mode Voltage (V)
|
Input Offset, max, mV
|
Input Offset Drift, Max, uV/degC
|
Max gain error
|
Max gain drift (ppm/°C)
|
Gain (V/V)
|
CMRR (dB)
|
3dB BW (KHz)
|
Slew Rate (V/us)
|
Noise Floor (nV/sqrtHz)
|
Max Swing From Rail (V)
|
Temperature operating Range (°C)
|
Package
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 2.5~18 | 1 | -0.3~26 | 0.018 | 0.5 | 0.005 | 10 | 50 | 105 | 80 | 0.65 | 25 | 0.05~ Vsp-0.2 | -40~125 | SC70-6L | |
| 2.5~18 | 1 | -0.3~26 | 0.018 | 0.5 | 0.005 | 10 | 100 | 105 | 30 | 0.65 | 25 | 0.05~ Vsp-0.2 | -40~125 | SC70-6L | |
| 2.7~30 | 1 | -0.3~30 | 0.015 | 1 | 1% | 10 | 50 | 105 | 120 | 1.5 | 30 | 0.002~ Vsp | -40~125 | SC70-6L | |
| 2.7~30 | 1 | -0.3~30 | 0.015 | 1 | 1% | 10 | 50 | 105 | 50 | 1.5 | 30 | 0.002~ Vsp | -40~125 | SC70-6L | |
| 2.7~30 | 1 | -0.3~30 | 0.015 | 1 | 1% | 10 | 50 | 105 | 20 | 1.5 | 30 | 0.002~ Vsp | -40~125 | SC70-6L | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 20 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | SOIC-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 50 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | SOIC-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 100 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | SOIC-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 20 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | TSSOP-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 50 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | TSSOP-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 100 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | TSSOP-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 20 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | MSOP-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 50 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | MSOP-8 | |
| 2.7~5.5 | 1 | -6~80 | 0.015 | 0.6 | 0.0001 | 5 | 100 | 162 | 560 | 1.5 | 85 | 0.001~VS-0.005 | -40~125 | MSOP-8 | |
| 2.7~5.5 | 1 | -0.3~40 | 0.001 | 0.02 | 0.001 | 20 | NA | 160 | NA | NA | NA | NA | -40~125 | MSOP-10 | |
| 2.7~5.5 | 1 | -5~65 | 0.0025 | 0.15 | 0.001 | 30 | NA | 168 | NA | NA | NA | NA | -40~125 | MSOP-10 |
